LT-YS61AJ Three-Side Seal Packing Machine

LT-YS61AJ Three-Side Seal Packing Machine

LT-YS61AF automatic packaging machine for liquid, sauce and granule products. PLC + touch screen control, PID temperature control (error ≤1°C), stepper motor driven. Fully automatic process (filling, sealing, cutting) with 3-side sealing option. Custom batch printing available for food, chemical and cosmetic applications.

Description：

This machine adopts the touch screen operation, PLC control, drive stepper motor to control the bag length,stable performance,

easy to adjust and accurate detection.Choose the intelligent temperature controller and PID control to ensure

the error range of temperature controlled within 1 degree Centigrade.

Application:

The machine is suitable for the food, chemical industry, cosmetics industry of liquids,

sauce of measurement packing,such as honey, jam, tomato sauce, shampoo, fruit juice, beverages, etc.

Technical parameters：

Model LT-YS61AJ

Voltage 220V

Power 1.4KW

Packing type Three side sealing (optional back side sealing or four side sealing)

Packing speed 30-60bags/min

Bag length 30-170mm

Bag width 30-130mm(Need to replace the bag former

Filling range 1-100g(3 - 100ml)

Machine weight 400kg

Machine size 900 *1100*1900 mm

Ordering Information

Please provide the material to be packed, target weight or volume, bag dimensions, packaging film and required output. Confirm the dosing and sealing configuration.

Warranty and Lead Time

The standard equipment warranty is generally one year. The usual lead time for standard equipment is 3–5 days. Custom equipment lead times are confirmed after discussing the specifications. Please confirm warranty and delivery details in your quotation.

Request a quote: portiaxie@fillinglabeling.com | WhatsApp +86 15070838530. See our contact page for our locations.
