LTPK LT-002 Automatic Soft Tube Filling And Ultrasonic Sealing Machine


Product Description

This semi automatic machine is suitable for filling liquid or paste into soft tubes and sealing tubes.The fixing mold of this machine can be customized according to tube size.It is also equipped with coding function which can be used to print production date on soft tube.This machine is widely used in daily chemical,cosmetics industries.

Product Feature

1. Independent research and development of digital automatic ultrasonic automatic frequency tracking electric box, no need to manually adjust the frequency, increase the power automatic compensation function, will not cause the machine power to drop due to long use time, can automatically adjust the power according to the hose material and size, and handle the stability and failure The rate is extremely low, and the service life is longer than ordinary electric boxes;

2.Controlled by PLC touch screen, easy to operate;

3.The whole machine is made of 304 stainless steel, corrosion resistance, acid and alkali resistance;

4.Adopt Japanese Panasonic high-sensitivity calibration electric eye equipped with stepping motor, fast and accurate calibration;

5.Using a dual-purpose filling machine for paste and liquid, the filling accuracy can be controlled within ±1 Cream Filling Machine Soft Tube Filler And Sealer Plastic Tube Filling And Sealing Machine

Technical Parameters

Model :LT-002

Input power :AC220V/50Hz   AC110V/60Hz

Power: 2000W

Ultrasonic frequency: 20Khz

Soft tube length: 50-200mm

Soft tube diameter :10-50 mm

Filling: 6-60,10-120,25-250ml

Machine size About :860*680*1550mm

Package size About :1000*810*1430mm

Net weight/Gross weight :About 130kg/150kg
